Focus Industries PL-23-SWDM-LEDP Series 4W LED 3000K Bollard Light 12V

Focus Industries PL-23-SWDM-LEDP Series 4W LED 3000K Bollard Light 12V

Specifications:

• Construction: Extruded 2.25 inch square aluminum or brass.
  -S2 models have 2, 6 inch light openings
  -S3 models have 3, 6 inch light openings
  -S4 models have 4, 6 inch light openings
• LED Panel: 4w, 300 lumen integrated LED flat panel, warm white 3000K; optional cool white 5200K 320 lumen available
• LED Lifetime Rating: 50,000 Hours
• LED Internal Driver: 5w 350mA output, 12v AC input. Voltage range of 10 to 15 volts. For use with magnetic transformers only.
• Wiring: Black 3 foot 18/2 zip cord from base of fixture (12v only) For 25 foot 16/2 fixture lead wire add -25F to catalogue number.
• Connection: FA-05 Quick Connector (not supplied) from fixture to main cable (12/2, 10/2 or 8/2 only)
• Mounting: FA-03-LG black 9 inch ABS stake, tapped 1/2 inch NPS
• Finish: Aluminum- Black texture polyester powder coat. Optional finishes available, Brass- Unfinished brass. Optional finishes available
• Note: Optional External 120v LED available.

Product Files

Click for PL-23-s2wdM-LEDP Specification Sheet

Click for PL-23-s2wdM-LEDP Installation Instructions

Click for Focus Finish Options
